Description: SPEED-X 60D 2D Wirless 2.4Ghz barcode scanner With Stand -
(2D CMOS Wireless 2.4G Handheld Barcode Scanner)
Technical Parameters
Wireless specifications
Communications 2.4GHz
Communication frequency 2.402 to 2.480GHz
Transmission range ≤30M（In empty area 30M ）
Data rate 1Mbps
Memory 100000@13Byte barcode
Battery capacity 1500mAh (Lithium battery)
Charging time 4.5H
The life time of the full charge 4h（continuous reading situation）
9.5h（Manual reading situation）
More than 15 days （Stand-by time)
Communication mode Read-time mode/Inventory mode
Electrical Characteristics
Interface USB HID KEYBOARD（Wireless receiver）
Voltage requirement Max:120mA
Min：50mA
Optical Characteristics
Photo sensor CMOS array sensor
SENSOR RESOLUTION 648 X 488 Pixels
Light source White LED
Aim light source Red Bar LED
Performance Characteristics
Decode angle Pitch angle:±60°;Skew angle:±60°;Tilt angle:±180°
Min resolution 1D≥4mil
2D≥10mil
Min.PCS value 〉15% UPC/EAN 13（13mil）
Field of View 46°(H),35°(V)
Identification 1D： Codabar，Code128，Code11，Code32，Code39，Code93，Composite，EAN/UPC,EAN-8,EAN-13,GS1 DataBar Expanded，GS1 DataBar Limited，GS1 DataBar Omnidirectional，Hong Kong 2 of 5（China Post），Interleaved 2 of 5，Matrix 2 of 5 Pharmacode. RSS-14,RSS-LIMITED, RSS-EXPANDED, Industrial 2 of 5,Telepen,Trioptic Code, UPC-A,UPC-E
2D：Aztec Code，Codablock F，DOT_CODE, HANXIN, Maxicode，MicroPDF417，Micro QR Code，MSI，PDF417,QR Code, DataMatrix
Physical Characteristics
Dimensions Scanner：95mm×70mm×168mm（L x W x H）
Receiver：83mm*18mm*13mm(L*W*H)
Weight Scanner：186g
Receiver：16g
Environmental Characteristics
Temp 0°∽50°C / 32°∽122°F(operation) /-10°∽60°C /14°∽140°F(storage)
Humidity 20 - 85% (operation) ) 20 - 95% (storage)
Shock drop test 1.5m drop onto concrete surface
Ambient Light: fluorescent light 4000 lx max ,
direct sun light 80,000 lx max ,white light 4000 lx max
Decoding Depth of Field
Symbology Resolution Nearest Farthest
Code 39 20mil 5.5cm 35cm
Code 128 15mil 6cm 31cm
EAN-13 13.34mi 6cm 25cm
QR code 20mil 4cm 21cm
PDF417 13.34mil 3cm 29cm
